Electrophysiology Catheters

EPR-800, EPR-801, EPR-802

Configurations


Status message

Please select which product configuration you would like to add to your cart.

Electrophysiology Catheter (1.1F, 8E, 1.0 mm, 4.5 cm, Redel, Non Repairable)

EPR-800

$2,379.00 USD

For use in mice as small as 25 g.

  • Constructed from nylon and polyimide materials
  • 1.1 F (0.36 mm)
  • Reusable 8-electrode catheter

hourglassShips from Overseas
Estimated delivery time: 2 months.


Electrophysiology Catheter (1.1F, 8E, 1.0 mm, Lumen, 4.5 cm, Redel, Non Repairable)

EPR-801

$2,622.00 USD

For use in mice.

  • Constructed from nylon and polyimide materials
  • 1.1 F (0.36 mm)
  • Reuseable 8-electrode catheter​
  • Introducing lumen for sampling/slow speed injections.

hourglassShips from Overseas
Estimated delivery time: 2 months.


Electrophysiology Catheter (1.6F, 8E, 1.0 mm, 12.5 cm, Redel, Non Repairable)

EPR-802

$2,622.00 USD

For use in rats.

  • Constructed from nylon and polyimide materials
  • 1.6 F
  • Reusable 8-electrode catheter

hourglassShips from Overseas
Estimated delivery time: 2 months.


×

Configurations


Electrophysiology Catheter (1.1F, 8E, 1.0 mm, 4.5 cm, Redel, Non Repairable)

EPR-800

For use in mice as small as 25 g.

  • Constructed from nylon and polyimide materials
  • 1.1 F (0.36 mm)
  • Reusable 8-electrode catheter

Electrophysiology Catheter (1.1F, 8E, 1.0 mm, Lumen, 4.5 cm, Redel, Non Repairable)

EPR-801

For use in mice.

  • Constructed from nylon and polyimide materials
  • 1.1 F (0.36 mm)
  • Reuseable 8-electrode catheter​
  • Introducing lumen for sampling/slow speed injections.

Electrophysiology Catheter (1.6F, 8E, 1.0 mm, 12.5 cm, Redel, Non Repairable)

EPR-802

For use in rats.

  • Constructed from nylon and polyimide materials
  • 1.6 F
  • Reusable 8-electrode catheter

×

Electrophysiology Catheters

$2,379.00 USD-$2,622.00 USD

Used to perform standard electrophysiology studies by applying pacing and recording protocols from inside the heart (intracardiac) or through the esophagus (transesophageal) to determine electrical properties of the atrium and the ventricle.

Book a Demo

Overview

Electrophysiology catheters are specialised Millar Mikro-Tip Catheters, which are designed to be used with compatible stimulators/amplifiers (purchased separately) to perform standard electrophysiology studies. Depending on the features of the stimulator/amplifier, pacing and recording protocols can be performed from inside the heart (intracardiac) or through the esophagus (transesophageal) to determine electrical properties of the atrium and the ventricle, which include:

  • Conduction times
  • Refractory periods
  • His potentials
  • Sinus and atrioventricular nodal properties
  • Inducibility of abnormal heartbeats

Compatible hardware include any ADInstruments Bio Amp for recording functionality only or an Intracardiac Electrophysiology Stimulator/Amplifier for both stimulation and recording functionalities. Electrophysiology catheters also require a certain level of care to ensure accuracy and the anticipated lifespan of your catheters. For a few best practice tips to help get you started with your catheters, see our guide here.

Accessories (purchased separately):

Configurations


Electrophysiology Catheter (1.1F, 8E, 1.0 mm, 4.5 cm, Redel, Non Repairable)

EPR-800

For use in mice as small as 25 g.

  • Constructed from nylon and polyimide materials
  • 1.1 F (0.36 mm)
  • Reusable 8-electrode catheter

Electrophysiology Catheter (1.1F, 8E, 1.0 mm, Lumen, 4.5 cm, Redel, Non Repairable)

EPR-801

For use in mice.

  • Constructed from nylon and polyimide materials
  • 1.1 F (0.36 mm)
  • Reuseable 8-electrode catheter​
  • Introducing lumen for sampling/slow speed injections.

Electrophysiology Catheter (1.6F, 8E, 1.0 mm, 12.5 cm, Redel, Non Repairable)

EPR-802

For use in rats.

  • Constructed from nylon and polyimide materials
  • 1.6 F
  • Reusable 8-electrode catheter
×
checkmark Item successfully added to your quote request.
Electrophysiology Catheter (1.1F, 8E, 1.0 mm, 4.5 cm, Redel, Non Repairable)

Electrophysiology Catheter (1.1F, 8E, 1.0 mm, 4.5 cm, Redel, Non Repairable)

EPR-800

×
checkmark Item successfully added to your quote request.
Electrophysiology Catheter (1.1F, 8E, 1.0 mm, Lumen, 4.5 cm, Redel, Non Repairable)

Electrophysiology Catheter (1.1F, 8E, 1.0 mm, Lumen, 4.5 cm, Redel, Non Repairable)

EPR-801

×
checkmark Item successfully added to your quote request.
Electrophysiology Catheter (1.6F, 8E, 1.0 mm, 12.5 cm, Redel, Non Repairable)

Electrophysiology Catheter (1.6F, 8E, 1.0 mm, 12.5 cm, Redel, Non Repairable)

EPR-802

Details

Product Codes


EPR-800
Electrophysiology Catheter (1.1F, 8E, 1.0 mm, 4.5 cm, Redel, Non Repairable)
ce
EPR-801
Electrophysiology Catheter (1.1F, 8E, 1.0 mm, Lumen, 4.5 cm, Redel, Non Repairable)
ce
EPR-802
Electrophysiology Catheter (1.6F, 8E, 1.0 mm, 12.5 cm, Redel, Non Repairable)
ce
