LabChart features and expandable capabilities

Save and label your selections and analysis regions and recall them at a click. Whether you're using an automated Analysis Module like Blood Pressure, or simply making a selection for addition to the data pad, you can recall the same selection at any time post-analysis.

Our most powerful channel calculation allows you access to LabChart's calculation engine, allowing customized formulae, detection, and analysis. Take that equation direct from the textbook or article and build it within LabChart.

The central hub of your data acquisition system provides an overview of the current recording settings, calculations and channels. Quickly change your displayed channels or add a calculation.

Annotate your data during or post acquisition to aid in navigating your traces later and use your comments to unlock the full time-saving potential of LabChart's analysis and visualization features.

This tool combines flexible and clever cycle detection to create a simple to use analysis for periodic waveforms. Find your Heart Rate, Systolic Pressure, Respiratory Rate, integrate a waveform over a cycle, or simply mark events.

The most flexible method of converting your time based raw data and calculations from the chart view to discrete values for use in statistical analysis.

Find incredible flexibility in the way you acquire your signals. This dialog allows you to manage which LabChart channels will be acquiring data, and to manage from which devices and inputs that data will be provided.

Display your raw data or calculation signals as a large numerical display. This makes it simple to see the current status of any signal from across the room. Update in real time, or display a derived calculation every 10 seconds.

Initiate your LabChart updates from within the software, search for new LabChart add-ons or toggle off features and menus you aren't planning to use for this experiment. Optimize LabChart to fit your current needs, and simplify your workflow.

Visualize targets for human subjects, or simply highlight a section of your data trace to ensure you'll notice when you've reached your area of interest. Guidelines provide a quick but powerful way to divide your data amplitude in to regions of interest.

Clean up your display in LabChart with this extremely convenient feature. Use Smart Tile to quickly snap all of the open windows into a neat arrangement, or save your current display and revert back to it at any time with a simple mouse click.

Record your actions for repetitive operations, or get under the hood and write custom processes in VB Script. Editable macros provide access to most of LabChart's features, your imagination is the only limitation to streamlining your workflow and processes in LabChart.

Spread your LabChart workspace across multiple displays to keep chart view, analysis windows and reference material visible at the same time.

All PowerLab and Lt Sensors are compatible with LabChart 9. If a new file is created with multiple PowerLab Sensors connected, all of the Sensors will be automatically enabled. Sampling settings, including Range and Rate, can be edited for the Sensors that have these features available.

Display, overlay, average and analyze periodic or evoked waveforms in real time. Ideal for finding that time from stimulus to response in repeated evoked potential recordings.

Powerfully convert your time based signal to its component frequencies. You can display the power spectrum density, a colorful spectrogram, a channel calculation for quantifying the power in specific frequency ranges, or extract frequency parameters directly to the data pad.

See the chart view traces with two separate x-axis displays. View long term trends long side the latest data with this beautifully clever display feature.

The awesome flexibility in LabChart's stimulator dialog allows you to create a custom protocol to stimulate your preparation directly or to control an ADInstruments stimulus isolator or third-party device.

Our simple two point calibration tool makes converting Voltage units to known measurement units quick and simple.

Take a closer look at an event, compare the timing between two overlayed channels, and export your images to publish. The Zoom View provides a snapshot of your data.
